Overview
Specification
| Parameter | Specification / Description |
|---|---|
| Number of Channels | 8 output channels |
| Output Signal Type | 4–20 mA DC |
| Output Load Resistance | 0–750 Ω |
| Output Accuracy | ±48 µA |
| Data Update Period | 10 ms |
| Step Response Time | 40 ms |
| Transmitter Power Supply | 14.8–26.4 V DC |
| Temperature Drift | ±0.1% per 10 °C |
| Maximum Current Consumption | 410 mA at 5 V DC, 290 mA at 24 V DC |
| External Connections | Pressure clamp terminals, KS cable |
| HART Communication | Supported on current outputs for monitoring and diagnostics |
| Isolation | Channel-to-channel and channel-to-ground isolation for safety |
| Redundancy Support | Compatible with dual-redundant ESB/ER bus configurations |
| Operating Temperature Range | 0–55 °C (standard), extended range optional |
| Storage Temperature Range | -25–70 °C |
| Humidity | 5–95% RH, non-condensing |
| Vibration Resistance | 10–57 Hz, 0.075 mm amplitude; 57–150 Hz, 9.8 m/s² |
| Shock Resistance | 147 m/s² (15 G), 11 ms half-sine |
| Dimensions (WxHxD) | 30 mm × 152 mm × 110 mm |
| Weight | 0.3 kg |
| Mounting | DIN rail or rack mount compatible |
| Certifications | CE, CSA, and other industrial standards |
FAQ
A1: The module provides 8-channel 4–20 mA DC analog outputs suitable for process control devices.Q2: Is the module compatible with HART communication devices?
A2: Yes, it supports HART communication on current outputs for monitoring and diagnostics.
Q3: Can the AAI543-S50 be used in redundant systems?
A3: Absolutely. It supports dual-redundant ESB/ER bus configurations to ensure uninterrupted operation.
Q4: What is the maximum load resistance for each output channel?
A4: Each output channel supports a maximum load resistance of 750 Ω.
Q5: What are the operating temperature and environmental conditions?
A5: It operates reliably between 0–55 °C, with 5–95% non-condensing humidity, and withstands vibration and shock.
Q6: How precise and fast is the module’s output response?
A6: It provides ±48 µA accuracy with a 10 ms data update period and a 40 ms step response time.
