Overview
In addition, its integral PTFE-insulated cable delivers excellent electrical stability and resistance to oil, moisture, and chemicals, making it suitable for continuous operation in turbines, compressors, and large electric motors. The 330425-01-00 integrates seamlessly with Bently Nevada 3500, 3701/46E, and Trendmaster Pro systems, ensuring accurate data capture and streamlined system compatibility.
Specification
| Parameter | Specification |
|---|---|
| Model | Bently Nevada 330425-01-00 |
| Transducer Type | Piezoelectric accelerometer |
| Sensitivity (±5%) | 100 mV/g (10.2 mV/m/s²) |
| Measurement Range | ±245 m/s² (±25 g) |
| Frequency Range (±3 dB) | 2 Hz to 10,000 Hz |
| Mounted Resonant Frequency | >25 kHz |
| Amplitude Linearity (1–25 g pk) | ±1% |
| Transverse Sensitivity | ≤5% |
| Output Bias Voltage | +10 VDC ±0.5 V |
| Power Supply (Constant Current) | 2–10 mA at 18–30 VDC |
| Broadband Noise (1 Hz–10 kHz) | ≤50 µg rms |
| Output Impedance | <100 Ω |
| Operating Temperature Range | -54°C to +121°C (-65°F to +250°F) |
| Shock Limit (Peak) | 4900 m/s² (500 g) |
| Case Material | 316 Stainless steel |
| Sealing | Hermetic (welded construction) |
| Connector / Cable | Integral, PTFE-insulated cable |
| Mounting Thread | 1/4-28 UNF |
| Agency Approval Option | CSA, ATEX, IECEx |
| Weight | Approx. 90 g (3.2 oz) |
| Compatible Systems | Bently Nevada 3500, 3701/46E, Trendmaster Pro |
FAQ
Q1: What makes the 330425-01-00 different from standard accelerometers?
It provides superior stability, hermetic sealing, and optimized compatibility with Bently Nevada monitoring systems.
Q2: Can this sensor be used in hazardous environments?
Yes. It includes CSA, ATEX, and IECEx certifications for safe use in industrial hazardous areas.
Q3: What is the recommended installation method?
Mount it using a 1/4-28 UNF thread for optimal mechanical coupling and accurate vibration transfer.
Q4: Which monitoring systems is it compatible with?
It integrates directly with Bently Nevada 3500, 3701/46E, and Trendmaster Pro systems.
