Overview
Specification
| Parameter | Specification |
|---|---|
| Brand | Rockwell Automation / Allen-Bradley |
| Model Number | 1492-ACABLE010WB |
| Module Type | ControlLogix Analog Cable Connection Module |
| System Compatibility | Allen-Bradley ControlLogix analog I/O modules |
| Connector Type | Multi-pin with secure locking mechanism |
| Cable Type | Shielded analog cable for EMI and RFI protection |
| Number of Conductors | 10 conductors for signal and ground connections |
| Conductor Material | Tinned copper wires for low-resistance and long-term reliability |
| Insulation Material | High-performance PVC or equivalent polymer |
| Cable Shielding | Braided copper shield with foil layer |
| Cable Jacket | Flame-retardant, oil-resistant polymer |
| Cable Length | Standard 1 m (custom lengths available upon request) |
| Operating Temperature Range | -40°C to 70°C (-40°F to 158°F) |
| Storage Temperature Range | -40°C to 85°C (-40°F to 185°F) |
| Voltage Rating | 300 V AC/DC maximum |
| Current Rating | 5 A maximum per conductor |
| Certifications | UL Listed, CE Marked, RoHS Compliant |
| Mounting Type | Panel or rack-mounted with quick-connect interface |
| Key Features | High-density I/O support, easy installation, robust design |
| Environmental Protection | Resistant to dust, oil, and industrial contaminants |
FAQ
A1: It is compatible with most analog I/O modules. Always verify specific module requirements before installation.
Q2: Can the cable length be customized?
A2: Yes, Rockwell Automation offers custom lengths to fit specific system configurations.
Q3: How does this module handle electrical interference?
A3: Its braided and foil shielding provides excellent protection against EMI and RFI, ensuring reliable signal transmission.
Q4: What are the operating environment limits?
A4: The module operates between -40°C and 70°C and resists dust, oil, and industrial contaminants.
Q5: How can I maintain or troubleshoot the module?
A5: Maintenance is minimal. Regularly inspect connectors and shields. Diagnostics tools in ControlLogix systems assist with troubleshooting.
