Overview
Specification
| Parameter | Specification |
|---|---|
| Brand | Rockwell Automation / Allen-Bradley |
| Model Number | 1492-ACABLE010UB |
| Module Type | ControlLogix Analog Cable Connection Module |
| System Compatibility | Allen-Bradley ControlLogix analog I/O modules |
| Connector Type | Multi-pin with secure locking mechanism |
| Cable Type | Shielded analog cable for EMI and RFI protection |
| Number of Conductors | 10 individual conductors for signal and ground |
| Conductor Material | Tinned copper wires for low-resistance connection |
| Insulation Material | High-performance PVC or equivalent polymer |
| Cable Shielding | Braided copper shield with foil layer |
| Cable Jacket | Flame-retardant, oil-resistant polymer |
| Cable Length | Standard 1 m (custom lengths available upon request) |
| Operating Temperature Range | -40°C to 70°C (-40°F to 158°F) |
| Storage Temperature Range | -40°C to 85°C (-40°F to 185°F) |
| Voltage Rating | 300 V AC/DC maximum |
| Current Rating | 5 A maximum per conductor |
| Certifications | UL Listed, CE Marked, RoHS Compliant |
| Mounting Type | Panel or rack-mounted with quick-connect interface |
| Key Features | High-density I/O support, easy installation, robust design |
| Environmental Protection | Resistant to dust, oil, and industrial contaminants |
FAQ
A1: The 1492-ACABLE010UB is compatible with most ControlLogix analog input and output modules. Always verify module-specific compatibility in the product datasheet before installation.
Q2: Can the cable length be customized for specific system layouts?
A2: Yes, Rockwell Automation offers custom cable lengths to accommodate unique installation requirements or complex rack configurations.
Q3: How does the module handle industrial electrical interference?
A3: The cable features braided copper shielding with a foil layer, providing excellent protection against EMI and RFI, ensuring reliable signal integrity.
Q4: What are the environmental limitations of the 1492-ACABLE010UB?
A4: The module operates reliably in temperatures from -40°C to 70°C and is resistant to dust, oil, and other industrial contaminants.
Q5: How do I maintain or troubleshoot the module?
A5: Maintenance is minimal; regularly inspect connections and shields for damage. Faults are usually easy to diagnose using standard ControlLogix I/O diagnostics tools.
