Overview
In addition, the T9110 actively communicates with other processor modules, whether inside the same chassis or across the wider control network, ensuring synchronization and system-wide consistency. At the same time, it launches periodic diagnostics that verify the health and performance of the controller without disrupting normal operation.
The module also integrates seamlessly with external systems such as HMIs, allowing operators to monitor and control processes effortlessly. Moreover, its robust communication protocols enable secure message encapsulation and verification, keeping data reliable throughout the network.
Ultimately, the T9110 delivers a smooth balance between high-speed processing, fault tolerance, and advanced safety, making it a core element of the AADvance platform.
Specification
| Parameter | Value |
|---|---|
| Manufacturer | Rockwell / ICS Triplex |
| Model | T9110 |
| Series | AADvance |
| CPU | PowerPC 604e, 400 MHz |
| Memory | Boot Flash: 512 kB; SRAM: 512 kB; Bulk Flash: 64 MB; SDRAM: 32 MB |
| Power Supply | Redundant 24 V DC (range 18–32 V) |
| Power Dissipation | ≈ 8 W |
| I/O Interface | Backplane connection to standard ICS Triplex I/O modules |
| Communication Ports | 2 Ethernet ports + 2 RS-232 / RS-422 ports |
| Redundancy Modes | Simplex, dual, or triple processor configuration |
| Diagnostics & Safety | Periodic self-test, voting logic, secure communication protocols |
| Dimensions | ~ 166 mm × 42 mm × 118 mm |
| Weight | ≈ 430 g |
| Operating Temp | –30 °C to +80 °C |
FAQ
A: Yes, we supply 100% original ICS Triplex / Rockwell modules with full warranty.
Q: What is the typical delivery time?
A: We ship within 3 days to 2 weeks, depending on order size and courier.
Q: How does the redundancy work?
A: You can configure one (simplex) or multiple (dual/triple) T9110 modules. In dual or triple mode, fault detection and fail-over logic keep the system running.
Q: Which communication protocols are supported?
A: It supports Modbus RTU, Open Modbus/TCP, and proprietary AADvance protocols over Ethernet and serial links.
Q: Can I replace one processor while others stay in operation?
A: Yes, in dual/triple redundancy mode you can hot-swap a processor without stopping the controller.
