Overview
Specification
| Parameter | Specification |
|---|---|
| Model | T8314 |
| Manufacturer | Rockwell Automation |
| Series | ICS Triplex Trusted System |
| Module Type | Fibre Transmit/Receive (TX/RX) Unit |
| Architecture | Triple Modular Redundant (TMR) |
| Communication Type | Fibre optic communication |
| Transmission Speed | Up to 2 Mbit/s |
| Maximum Fibre Length | 1000 m (multimode fibre) |
| Fibre Type | 62.5/125 µm multimode |
| Connector Type | ST or SC fibre connectors |
| Diagnostic Function | Continuous link and signal integrity monitoring |
| Operating Voltage | 24 V DC nominal |
| Power Consumption | 4.8 W typical |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (H × W × D) | 186 × 40 × 130 mm |
| Weight | 0.35 kg (approx.) |
| Mounting Type | Chassis-mounted |
| Certifications | CE, ATEX, UL-compliant |
FAQ
Yes, every T8314 module is 100% new and original from Rockwell Automation.Q2: Do you have this product in stock?
Yes, we maintain ready stock, and typically ship orders within 3 days to 2 weeks, depending on the order quantity.
Q3: What shipping methods are available?
We primarily use DHL, FedEx, or UPS for reliable and fast international delivery.
Q4: What is your return policy?
We offer a 30-day return guarantee if the product encounters any quality issues.
Q5: How far can the T8314 transmit data via fibre optics?
The T8314 supports fibre connections up to 1000 meters, ensuring reliable long-distance communication.
Q6: What makes the T8314 suitable for harsh environments?
The T8314 features a robust chassis-mounted design, operates between -20°C and +60°C, and resists electrical interference through optical isolation.
