Overview
Specification
| Parameter | Specification |
|---|---|
| Model | 6AV7892-0BD30-0AA0 |
| Product Type | HMI Operator Panel / Touchscreen Interface |
| Display Size | 12 inches |
| Display Resolution | 1280 × 800 pixels |
| Screen Type | Capacitive touchscreen, multi-touch |
| Operating System | WinCE-based Siemens HMI software |
| Connectivity | Ethernet, USB, PROFINET |
| Power Supply | 24 V DC |
| Operating Temperature Range | 0–55 °C |
| Protection Class | IP65 (front), IP20 (rear) |
| Dimensions (W×H×D) | 349 × 247 × 46 mm |
| Mounting | Panel-mount installation |
| Compliance | CE, UL, RoHS |
| Memory | Integrated RAM/Flash memory for HMI projects |
FAQ
A: This model belongs to the IPC677C series. While certain variants may be phased out, many distributors still offer spare parts and repair services.
Q: What operating systems can run on this unit?
A: The IPC677C is compatible with common industrial OS environments. Historically, Windows (e.g., Windows 7) was supported, but verify the OS version with your supplier.
Q: Can I expand its storage or I/O?
A: Yes — two PCI slots are free, allowing you to add expansion cards as needed for your application.
Q: How does it handle power fluctuations or failure?
A: It features built-in monitoring for temperature and fans, plus watchdog logic. For power failure handling, you may pair it with an external UPS module depending on your setup.
Q: What environment is this designed for?
A: It’s optimized for industrial automation, such as control cabinets, machine operator stations, and manufacturing cells, where robust performance and continuous operation are critical.
