Overview
Built with 316 stainless steel construction and hermetic welding, this accelerometer ensures long-lasting reliability even in the harshest plant environments. Moreover, the integral PTFE-insulated cable maintains excellent electrical stability while resisting oil, moisture, and chemical contamination. As a result, users can count on consistent and accurate data under demanding operating conditions.
In addition, the 330425-02-05 integrates smoothly with Bently Nevada 3500, 3701/46E, and Trendmaster Pro systems, allowing efficient data transfer and simplified installation across existing monitoring setups. Furthermore, its low noise output and wide frequency response make it ideal for continuous monitoring of turbines, compressors, pumps, and large electric motors.
Specification
| Parameter | Specification |
|---|---|
| Model | Bently Nevada 330425-02-05 |
| Transducer Type | Piezoelectric accelerometer |
| Sensitivity (±5%) | 100 mV/g (10.2 mV/m/s²) |
| Measurement Range | ±245 m/s² (±25 g) |
| Frequency Range (±3 dB) | 2 Hz to 10,000 Hz |
| Mounted Resonant Frequency | >25 kHz |
| Amplitude Linearity (1–25 g pk) | ±1% |
| Transverse Sensitivity | ≤5% |
| Output Bias Voltage | +10 VDC ±0.5 V |
| Power Supply (Constant Current) | 2–10 mA at 18–30 VDC |
| Broadband Noise (1 Hz–10 kHz) | ≤50 µg rms |
| Output Impedance | <100 Ω |
| Operating Temperature Range | -54°C to +121°C (-65°F to +250°F) |
| Shock Limit (Peak) | 4900 m/s² (500 g) |
| Case Material | 316 Stainless steel |
| Sealing | Hermetic (welded construction) |
| Connector / Cable | Integral, PTFE-insulated cable |
| Mounting Thread | 1/4-28 UNF |
| Mounting Thread Option | M8 x 1 integral stud |
| Agency Approval Option | Multiple approvals (CSA, ATEX, IECEx) |
| Weight | Approx. 90 g (3.2 oz) |
| Compatible Systems | Bently Nevada 3500, 3701/46E, Trendmaster Pro |
FAQ
A1: It works seamlessly with Bently Nevada’s 3500, 3701/46E, and Trendmaster Pro monitoring platforms.
Q2: Can this accelerometer operate in high-temperature environments?
A2: Yes, it performs reliably in temperatures from -54°C to +121°C (-65°F to +250°F).
Q3: Does the sensor require regular calibration?
A3: Routine calibration is recommended annually to maintain optimal accuracy and signal integrity.
Q4: What are the advantages of its hermetically sealed housing?
A4: The hermetic seal prevents moisture and contaminants from affecting the internal piezoelectric element, ensuring long-term stability.
