Overview
Specification
| Parameter | Specification |
|---|---|
| Model | 177230-00-01-05 |
| Probe Type | Seismic Transmitter |
| Excitation Voltage | 12–30 Vdc (current limited to 40 mA) |
| Settling Time | <15 seconds within 2% of final value |
| Sensing Element Type | Ceramic / Shear |
| Mounted Resonant Frequency | >12 kHz |
| Transverse Sensitivity | <5% |
| Connector Pin C | Dynamic Acceleration Signal (unbuffered, referenced to Pin B) |
| Acceleration Output Signal | Unbuffered voltage from Pin C to Pin B |
| Acceleration Sensitivity | 10.2 mV/m/s² (100 mV/g) ±20% |
| Acceleration Full Scale Range | 147 m/s² (15 g) peak |
| Acceleration Frequency Response | 2.5 Hz–10 kHz ±10% |
| Acceleration Linearity | ±1% of full scale |
| Output Bias | 2.5 V ±0.1 V |
| Measurement Range | 0–12.7 mm/s (0–0.5 in/s) |
| Frequency | 10 Hz–1 kHz (600 to 60 kcps) RMS |
| Approvals | Multiple Approvals (CSA/NRTL/C, ATEX/IECEx) |
FAQ
A: Yes, it interfaces directly with PLCs, DCS, or SCADA systems without field configuration.
Q: What outputs does it provide for vibration monitoring?
A: The transmitter offers a 4–20 mA velocity loop and an unbuffered acceleration voltage signal.
Q: Does the 177230 require calibration or additional setup?
A: No, it operates with a simple interface and minimal configuration requirements.
Q: What is the operating temperature range?
A: The transmitter operates reliably from 0°C to +45°C (+32°F to +113°F).
Q: Which certifications does this transmitter carry?
A: It is approved by multiple regulatory bodies, including CSA/NRTL/C and ATEX/IECEx.
