Overview
Furthermore, it enables engineers to execute monitoring, control, and automation tasks effectively, while simultaneously integrating seamlessly into diverse industrial environments. Consequently, it enhances system performance, and as a result, the unit consistently provides reliable and stable operation throughout continuous industrial use.
Specification
| Specification | Details |
|---|---|
| Product Type | Central Processing Unit (CPU) |
| Series | Advant Controller 31 |
| Manufacturer | ABB |
| Product ID | 1SBP260011R1001 |
| Input Voltage | 24 VDC |
| Output Voltage | 24 VDC |
| Digital Inputs | 8 channels |
| Relay Outputs | 6 channels |
| Communication Interface | CS31 Bus |
| Degree of Protection | IP20 |
| Operating Temperature | 0 … +55 °C |
| Storage Temperature | -25 … +75 °C |
| Country of Origin | Germany |
| Customs Tariff Number | 85389091 |
| Certificates | CE, UL, CSA, DNV, LR |
| Weight | Approximately 0.59 kg |
| Max Extension Units | 6 binary or analog units |
| Max CS31 Bus Length | 500 m (without amplifier), 2000 m (with amplifier) |
FAQ
Q: What is the maximum number of extension units that can be connected to the 07KP51?
A: The ABB 07KP51 supports up to 6 binary or analog extension units for flexible I/O expansion.
Q: What is the operating temperature range for the 07KP51?
A: It operates within 0 … +55 °C, ensuring stable performance in industrial environments.
Q: Can the 07KP51 be used in hazardous locations?
A: With IP20 protection, it is suitable for non-hazardous environments. Additional protective measures are required for hazardous areas.
Q: Is the 07KP51 compatible with other ABB automation systems?
A: Yes, it integrates seamlessly with the Advant OCS/800xA system and other ABB automation components.
Q: What certifications does the 07KP51 have?
A: The unit holds CE, UL, CSA, DNV, and LR certifications for international safety and quality standards.
